Get the details of a node pool of a Kubernetes cluster

Retrieve the details of a node pool of a Kubernetes cluster within your space.

Permissions

info

This action requires the following IAM (Identity and Access Management) permissions:

• kubernetes.cluster.get

Console

1. From the left-hand side menu, click Managed Services → Kubernetes to access the list of Kubernetes clusters.

2. Click the ID of the cluster containing the node pool whose details you want to view.

3. The information for each node pool appears in the Node pools section of the cluster details page.

You will find the following information there for each node pool:

• ID: unique identifier of the node pool;
• Status: current state of the node pool;
• Availability Zone: zone in which the node pool is deployed;
• Node type: profile of the nodes of the node pool;
• System volume: type and size of the system volume;
• Number of nodes: number of active nodes in the node pool.

API

Use the GET /kubernetes/spaces/{spaceId}/clusters/{clusterId}/nodePools/{nodePoolId} route to get the information of a node pool of a managed Kubernetes cluster.

Example response

{
  "id": "nodepool-001-e29b-41d4-a716",
  "name": "worker-nodepool-1",
  "availabilityZone": "eu-west-2a",
  "nodeProfile": "medium",
  "replicas": 3,
  "rootDisk": {
    "size": 50,
    "iops": 3000,
    "type": "enterprise"
  },
  "status": {
    "state": "RUNNING",
    "message": "NodePool is healthy"
  }
}

See the full specification
