Create a Hybrid Bridge

Reviewed on · View on GitHub

You can create a bridge in a space between one of your VPC (Virtual Private Cloud) and the managed services so that they can communicate with each other.

Permissions​

info

This action requires the following IAM (Identity and Access Management) permissions:

  • connectivity.bridge.create

Before you start, make sure you have:

  • the ID of the VPC you want to connect;
  • the ID of the space (the bridge will give access to all the managed services of the space);
  • the managed service must be exposed privately (visibility: INTERNAL).

Configuration required for the Hybrid Bridge to work​

You must configure your VPC to allow traffic to and from its bridge. This includes configuring the route table, and updating the rules of the security groups.

Route Table configuration​

In the route tables associated with the subnets of your VPC, create a route for each item in the bridge's routes array:

  • the ipRange as the destination;
  • the gatewayId as the target.

Security Group configuration associated with the VM of your VPC​

Add the following rules:

  • one or more rules allowing outbound traffic to the managed services;
  • one or more rules allowing inbound traffic from the managed services if required.

Your bridge is configured, and the VPC can communicate with the managed services over a private connection.

API​

The POST /connectivity/spaces/{spaceId}/bridges command lets you create a bridge between a VPC and the managed services of the space.

Request body:

{
  "left": {
    "id": "vpc-12345678",
    "type": "compute"
  },
  "right": {
    "id": "0194f0c4-8452-77d1-aaaf-516a9731ce9e",
    "type": "managedservice"
  }
}

Example request: Creating a Bridge

tip

Creating a bridge is asynchronous. The API returns a 202 Accepted code and the created object is partial (the routes array is not populated).

To obtain the bridge's routes, use the read endpoint after creation.
